OpenCV Package Configuration

OpenCV Package Configuration

  1. the libopencv-dev Is Not Installed
  2. C++ Files Using OpenCV Not Compiling

OpenCV is a machine learning library that provides various functions relating to Computer Vision applications. OpenCV can be used with C++, Python, Java, and MATLAB.

Since it is an external library not built into any programming language, it has to be installed separately on the system before use. While it is usually simple to install and run OpenCV, a few problems might cause the OpenCV library function not to work, such as missing packages or wrong syntax when compiling.

Below we will list a few common problems when installing and running OpenCV and how to fix them.

the libopencv-dev Is Not Installed

The libopencv-dev package is a supporting package for running OpenCV, and it contains some library binaries that are usually required for running OpenCV on Linux distributions, specifically Ubuntu.

When running a file containing OpenCV functions doesn’t execute, and the system shows the error message pkg-config cannot find OpenCV, it is usually due to the missing libopencv-dev package. This problem can easily be solved by installing libopencv-dev.

If you have installed OpenCV on the system with Linux package manager, then to install libopencv-dev, run the following command on the terminal.

sudo apt-get install libopencv-dev

If you have installed OpenCV to be used with Python using pip, you need to run the following command on the terminal.

sudo apt-get install libopencv-dev python-opencv
sudo pip install opencv-python

Note: For the above command, if you are using pip3 on your system, you must replace pip with pip3.

C++ Files Using OpenCV Not Compiling

Suppose you have already installed OpenCV on your system with all the relevant packages, and when compiling with G++, you get the undefined reference to OpenCV error. In that case, it is usually due to the syntax of the compile command.

For example, compiling with the following command will generate an undefined reference error.

g++ `pkg-config --cflags --libs opencv` test.cpp -o test

To fix this error, add the pkg-config --cflags --libs opencv at the end of the command like this:

g++ test.cpp -o test `pkg-config --cflags --libs opencv`

The above command will cause the file to compile and run successfully.

If you are using the correct syntax and the file still does not compile and generates an undefined reference error, it can be due to the version of OpenCV installed on your system not matching with the compile command; for example, if you are using OpenCV4, it is essential to add the 4 with the compile command as well.

g++ test.cpp -o test `pkg-config --cflags --libs opencv4`
